The contractor friendly printed circuit board eliminates the problem caused by incorrect wiring and saves hours of installation time.

I link 6 zone valve control for hydronic radiant floor heating.

The i link series zone valve controls simplify the field wiring and yet control up to six zone valves in a multi zone hydronic heating system. Zone valves can be used to regulate water flow in hydronic heating or cooling systems. The contractor friendly printed circuit board eliminates the problem caused by incorrect wiring and saves hours of installation time. There would be no more messy look of conventional zone valve.

The basic solution for controlling a system is to use a room thermostat designed for the relatively slow response times in floor heating or cooling. The i link series zone valve controls for hydronic radiant floor heating systems simplify the field wiring and yet control up to six zone valves in a multi zone hydronic heating system. Floor heating and cooling controls ensure the expected comfort level of floor heating and floor cooling systems are met. Can be used for cooling systems too.
