Height From Floor To Kitchen Sink P Trap Discharge

There won t be water in the sink.

Height from floor to kitchen sink p trap discharge.

According to the international residential code the maximum vertical distance between the sink drain and the entrance to the p trap is 24 inches. Its not the acceleration of water that makes it overflow into the drain the water itself seeks level. On mine this means a minimum of 8 vertical inches from the bottom of the sink to the bottom of the drain line. You you have a single bowl and disposer then offsetting either way 8 works.

Actually this configuration is acceptable. A riser off the trap into the sink is better off shorter than longer. You can miss by a few inches and the swivel of the trap will still pick it up. Well this doesn t really matter and is totally dependent on the trap outlet height.

A standard p trap looks like the one below. If you have a double bowl then aiming for the bowl drain opposite of the disposer works fine. The drain at the wall is a bit lower than the bottom of the sink. However the universal plumbing code stipulates.

This will vary depending on the height of the counter and. For a deep sink we stub out the sink trap arm at 16 above the floor. The trap and fixture drain for an automatic clothes washer standpipe shall be a minimum of 2 inches 51 mm in diameter. Those are the rules.

Under a double sink it might look like the garbage disposal isn t connected to a p trap but if you follow the pipe you ll see that it leads to a p trap even though the trap may be on the other side of the cabinet. Depends on where your trap outlet comes out of wall or meets below floor. The standard kitchen sink is 8 inches deep which means that the normal distance between a kitchen sink drain and the floor is 28 inches. This could be 6 inches or 2 feet.

Looking down at the drain in the sink you may see some water a bit further down but because the trap can be installed with the j bend flipped it gives you the room you need to make the connection. Don t forget to put your p trap no more than 24 below the sink drain. Doing the actual installation of all of the plumbing itself is not that hard and can save you money on a plumber. Per codes a trap has to be a minimum of 2 inches in depth and a maximum of 4 inches.

The waste from an automatic clothes washer shall discharge through an air break into a standpipe in accordance with section 802 4 or into a laundry sink.
